RADWAG

Precision balance PS 5Y M

Precision balance PS 5Y M

Regular price €2.470,00
Regular price €2.470,00 Sale price €2.470,00
Sale Sold out
Shipping calculated at checkout.

Price excl. VAT (VAT 0%)

SKU:WL-220-0407

Size (chamber volume)

Maximum capacity
Quantity
  • Installation and service: Metesa Finland Oy (optional)
  • Invoice or credit card · prices excl. VAT
  • Shipping calculated at checkout
  • Ask an expert: 020 730 7140

Estimated delivery time: 2–3 weeks

Warranty: 2 years

The RADWAG PS 5Y M precision balances of the ELLIPSIS series have a large weighing pan, internal automatic adjustment, LevelSENSING and a 10″ touchscreen with voice control.

Key highlights:

  • Maximum capacity: 200 g – 120 kg
  • Readability: 0.01 g – 0.2 g
  • Display: 10″ graphic colour touchscreen
  • OIML class -; IP 43
  • 2-year warranty

Technical data

Product category
Precision balance
Maximum capacity
200 g - 120 kg
Readability
0.01 g - 0.2 g
Display
10″ graphic colour touchscreen
External dimensions (W × D × H)
195×195 pan: 276 × 253.5 × 118 mm; other models: 206 × 333 × 107 mm; separate terminal 249 × 170 × 71 mm (W × D × H)
Weight
7.2 kg
Connections
2×USB-A, USB-C, RS 232 (COM3), HDMI, Ethernet, Wi-Fi, Hotspot
Standards
OIML class -; IP 43
Operating conditions
+10 – +40 °C, RH 40% – 80%
View full details

RADWAG

Precision balance PS 5Y M

The RADWAG PS 5Y M precision balances of the ELLIPSIS series have a large weighing pan, internal automatic adjustment, LevelSENSING and a 10″ touchscreen with voice control. Key highlights: Maximum capacity: 200 g – 120 kg Readability: 0.01 g – 0.2 g Display: 10″ graphic colour touchscreen OIML class -; IP 43 2-year warranty
  • Maximum capacity200 g - 120 kg
  • Readability0.01 g - 0.2 g
  • Warranty2 years
Request a quote
Precision balance PS 5Y M RADWAG

All features

  • Series: Precision balance PS 5Y M – 6 models
  • Display: 10″ graphic colour touchscreen
  • Adjustment: internal (automatic)
  • Leveling system: semi-automatic – LevelSENSING
  • Communication interface: 2×USB-A, USB-C, RS 232 (COM3), HDMI, Ethernet, Wi-Fi, Hotspot
  • Power supply: Adapter: 100 – 240V AC 50/60Hz 1A Max; 15V DC 2.4A Balance: 12 – 15V DC 1.4A max; 9 – 17W
  • Protection class: IP 43
  • Operating temperature: +10 – +40 °C
  • Relative humidity: 40% – 80%
  • Database capacity: 7
  • Touch-free operation: 2 IR Sensors
  • Delivery components: Balance, weighing pan, weighing pan shield, fabric dust cover, power supply
  • Functions: Autotest, Dosing, Percent Weighing, Parts counting, Newton unit, Peak hold, Formulation, Statistics, Checkweighing, IR sensors, Under-pan weighing, GLP Procedures, Animal weighing, Pipettes Calibration, Air density correction, Density determination, Ambient conditions, Differential weighing, Statistical Quality Control, Packaged Goods Control, ALIBI Memory, Wi-Fi
  • PS 10100.5Y.M (WL-220-0407): Max 10100 g, d = 10 mg, repeatability 12 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg
  • PS 4500.5Y.M (WL-220-0413): Max 4500 g, d = 10 mg, e = 100 mg, repeatability 8 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg
  • PS 2100.5Y.M (WL-220-0409): Max 2100 g, d = 10 mg, e = 100 mg, repeatability 8 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg
  • PS 6100.5Y.M (WL-220-0415): Max 6100 g, d = 10 mg, e = 100 mg, repeatability 8 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg
  • PS 8100.5Y.M (WL-220-0417): Max 8100 g, d = 10 mg, e = 100 mg, repeatability 10 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg
  • PS 3500.5Y.M (WL-220-0411): Max 3500 g, d = 10 mg, e = 100 mg, repeatability 8 mg, linearity ±20 mg, min. weight (USP) 10 g, pan 195×195 mm, net weight 7.2 kg

Specifications

Product categoryPrecision balance
Maximum capacity200 g - 120 kg
Readability0.01 g - 0.2 g
Display10″ graphic colour touchscreen
External dimensions (W × D × H)195×195 pan: 276 × 253.5 × 118 mm; other models: 206 × 333 × 107 mm; separate terminal 249 × 170 × 71 mm (W × D × H)
Weight7.2 kg
Connections2×USB-A, USB-C, RS 232 (COM3), HDMI, Ethernet, Wi-Fi, Hotspot
StandardsOIML class -; IP 43
Operating conditions+10 – +40 °C, RH 40% – 80%

Accessories and options

Brochures and downloads

Buying and service

  • Who installs and services the equipment?

    Installation, commissioning, maintenance, calibration and validation are carried out by our service partner Metesa Finland Oy. Service contracts are also available. Services are ordered separately – request a quote.

  • Are delivery and installation included in the price?

    No. Shipping costs are calculated at checkout. Delivery, carrying into place and installation are not included in the product price, but can be ordered as additional services.

  • How can I pay?

    You can pay by invoice or credit card. All prices are shown excluding VAT (VAT 0%).

Ask an expert

We help you choose the right size and configuration.

Need help choosing?

Our experts help you choose the right size and configuration. Delivery, installation and service in Finland.
