Frimed
Plasma freezer CV3/PF
CV3/PF Model (-30°C) CV3PFL225PCS - Digital control panel LGK-2 CV3PFA425PCS - Full touch control panel TP-1 Structure External structure in hot-dip galvanized steel, anti-corrosion treated and PVC film coated. Scotch-brite stainless steel internal structure. Insulation 80 mm of insulation obtained by injection of high density polyurethane CFC-free foam for excellent product preservation and best energy saving. Door Self-closing solid door,...
- Chamber volume160 l
- Temperature range-25…-32 °C
- Warranty2 years

All features
Specifications
Product categoryPlasma freezers –30° 40°C
Air circulationStatic (natural convection) – internal static evaporator
Chamber volume160 l
Temperature range-25…-32 °C
ControllerSelectable: LGK-2 digital control panel, TP-1 4" or TP-1 7" full touch panel; alarm system with alarm memory, data logger with USB download, remote volt-free alarm contact
Doorself-closing solid door; right hinge std, left on request
Shelves (standard / max)3 stainless steel drawers | max 3 shelves / 3 drawers
External dimensions (W × D × H)620 x 640 x 1400 mm (D x W x H)
External width640 mm
External depth620 mm
External height1400 mm
Internal width480 mm
See all specifications
Internal depth465 mm
Internal height720 mm
Weight95 kg
Connections230 V / 50 Hz
Power consumption320 W
Noise level<45 dB
RefrigerantR290 (CFC/HCFC-free)
StandardsMedical device, Regulation (EU) 2017/745 (MDR)
Accessories and options
Brochures and downloads
Buying and service
Who installs and services the equipment?
Installation, commissioning, maintenance, calibration and validation are carried out by our service partner Metesa Finland Oy. Service contracts are also available. Services are ordered separately – request a quote.
Are delivery and installation included in the price?
No. Shipping costs are calculated at checkout. Delivery, carrying into place and installation are not included in the product price, but can be ordered as additional services.
How can I pay?
You can pay by invoice or credit card. All prices are shown excluding VAT (VAT 0%).
Ask an expert
We help you choose the right size and configuration.
Need help choosing?
Our experts help you choose the right size and configuration. Delivery, installation and service in Finland.
